Quality control at every stage

Every job starts with an approved first-off, runs with patrol checks, and is released only after final inspection against the drawing.

Inspector measuring a metal component
Diameter
±0.01mm
Length
±0.02mm
Surface
Ra 0.8μm
Thread
6g / 6Hclass

Inspection stages

A part cannot move to the next stage until it passes the gate before it.

  1. Incoming

    Gate 01

    Raw material inspection

    • Mill certificate verified against grade
    • Bar diameter and straightness
    • Chemical composition checked against the mill certificate
    • Material segregated and tagged by alloy

    Awaiting part

  2. In-process

    Gate 02

    First-off and patrol inspection

    • First-piece approval before the run starts
    • Patrol checks at fixed intervals on every machine
    • Thread gauging go / no-go
    • Tool wear monitored and offsets recorded

    Awaiting part

  3. Final

    Gate 03

    Final inspection and release

    • Sampling plan against the drawing
    • Visual inspection for burrs and damage
    • Plating thickness verification
    • Inspection report issued with the lot

    Awaiting part

Measuring instruments

What each feature is checked with, from the machine to the inspection room.

  • Profile projectorProfiles, angles, radii and thread forms
  • Surface roughness testerRa / Rz on sealing and cosmetic faces
  • Digital height gaugeHeights, steps and positional features
  • Micrometers (outside, inside, bore)Diameters to 0.001 mm resolution
  • Thread plug and ring gaugesMetric, BSP, NPT and unified threads
  • Pin gauges and slip gaugesBores, slots and gauge calibration
  • Vernier and dial calipersGeneral dimensional checks at the machine
  • XRF / spectro analyserAlloy composition and plating thickness

Certifications

Our management systems are independently audited and certified.

Quality policy

Akshay Enterprise is committed to supplying components that conform to customer drawings and specifications, delivered on time. We achieve this through controlled processes, trained people, calibrated measuring equipment and continual improvement of our quality management system.

Read the full quality policy

Need inspection reports with every lot?

Tell us your documentation requirements when you request a quote.
